These are very good questions
I’ve split my answer into several sections - feel free to ask more. I didn’t manage to put these in-line so they’re all at the end of the post
- Difference between black boxes and functions
I’ll only talk about PURE functions. A pure function is one where all the inputs come in the arguments and the only output comes through the return value - it has no side effects.
A side effect can be thought as “leaving something behind” after the function has returned.
Most math functions are pure:
double(X) -> 2*X.
add(X, Y) -> X+Y.
etc.
Most OS calls are impure.
Imagine we open a file:
Handle = file:open("filename"),
The side effect is that the file is now opened, now we can do
file:read(Handle) this will return data (or eof) and the side effect
is that after this call the some position pointer with the file will have been updated.
Since functions cannot remember anything after they have returned we need a mechansim to remember things after the functions have returned.
We can do this inside a process:
In Erlang
loop(State) ->
receive
Msg ->
NewState = F(State),
loop(NewState)
end.
F can be a pure function, which given State returns NewState.
The current value of State is remembered by the process.
So processes basically remember state for you.
So what about Black boxes? These are things with inputs and outputs - the inputs and outputs are MESSAGES - inside a black box there can be one or more processes - the point about a black box is we’re not supposed to know how it works - ie we’re not allowed to peep in the inside and see how it’s made up.
- Difference between APIs and protocols
Imagine a file system with a simple API
file:open(FileName) => Handle
file:read(Handle) => {ok, Data} | eof
file:close(Handle) => ok
The notation F(Args) => A | B
means that the function F can return an A or N
This is an API but it says NOTHING about the allowable legal sequences of function calls.
For example the program fragment
Handle = file:open(FileName)
file:close(Handle)
file:read(Handle)
is NONSENCE - we can’t read a file after we have closed it - but the type system and the API does not tell us this.
A protocol is a description of the legal sequences of messages that a black box can process.
Now imagine the file API as messages going into a black box
so there is an open message that returns a handle, a read message that returns data or eof and so on.
Then a valid program could be represented by the regular expression
open read* close
ie we can open a file, do any number of reads then close the file
We might write the protocol as something like:
filesystem =
start -> open read* close start
Assuming the filesystem starts of in some magic state ‘start’
We can be more precise if we use a state machine:
open x closed -> Handle x opened
read x opened -> {ok,Data} x opened | eof x closed
close x Handle -> ok x closed
The file is has state open or closed, the messages are open
read and close, so rule 2 reads
if a file is in the state opened and gets a read request when
we either emit a {ok,Data} message and the next state in opened or we emit an eof message and go to the state closed
Note that the protocol provides far more information than the API in that it specifies the legal sequences of operations that the black box can perform.
- Principle of Observational Equivalence
Two systems are the same if they cannot be distinguished by observing their inputs and outputs - this is very important - it allows us to swap an implementation for a better one, change what happens inside the black boxes.
- Wiring things up and starting and stopping
Now we have to consider the wiring - and how we start and stop black boxes? - To do this we need yet another language, something like:
system X is:
start component a
start component b
...
connect out1 of a to in2 of b
connect out2 of b to in2 of c
..
send {logging,on} to control2 of c
..
send run to all
and we’re off - I assume start starts a black box and that run
makes it operational
Then
operation update means
send pause to all
send newcode1 to control2 of b
send resume to all
Or something
Most of this post was just thinking out loud - more about state machines for describing APIs is in the appendix of my PhD thesis it’s a system called UBF.
The ideas of describing protocols with communicating state machines comes from Tony Hoare’s CSP (Communicating Sequentail Programs)
The ideas of wiring up black boxes comes from Flow based Programming (Paul Morrison).
That’s enough for one posting
Cheers
/Joe
